Protection Engineering And Research Laboratories

Advanced
Overcurrent Protection

2 Days

Contents

• Steady state fault analysis

• Non-directional over-current and earth fault protection

• Directional over-current and earth fault protection

• Over-current & earth fault relay co-ordination procedure and tutorial

• Current transformer requirements for overcurrent and earth fault protection

• Testing and commissioning of over-current and earth fault protection systems

Objectives

This course will help electrical engineers to apply directional and non-directional over current relays to protect power system equipment. Participants of this course will gain knowledge to select the correct type of over-current & earth fault protection, calculate the settings to be adopted and to specify the optimum current transformers. The course will also provide them with knowledge required to find solutions for challenging situations in the field.
